User's Manual

Importing Connectivity
Inventory Management 5-51
Importing CSV Link Files
To import CSV link files, perform the following steps:
1. Access your environment staging server.
2. On the Active System Manager menu bar, click File > Import.
The Import—Select dialog box displays.
3. Select the CSV Link Import icon and click Next to display the Import dialog box with status
information about the CSV link file to import.
4. Click the Select input CSV file field and enter the CSV link file to import, or click Browse to search
for the CSV link file and click Next.
Figure 5-28 displays a sample excerpt from the CSV Link editor.
Figure 5-28 CSV Link Editor
5. On the Import dialog box, click Finish.
The Input CSV editor displays. The Import Explorer automatically identifies all invalid rows of the
CSV file, with errors. You can view these errors in the following views:
• Import editor—First column in the import editor for the invalid row as an image marked with red.
• Import editor—The details of the error in the columns Link Error.
To Dis Version Optional. Represents the resource version. If this is not provided, a link is
automatically created on the active version of the resource; otherwise, an
error displays.
To Location Represents the interface location of To Resource to be linked.
Sequence, Status and
Link Error
Output fields that are populated by the Active System Manager server when
the user validates links, imports links, and imports valid links.
Table 5-18 Field Properties of Link Inventory Spreadsheet (continued)
Field Description
