User's Manual

Importing Inventory
Inventory Management 5-47
Figure 5-25 New Inventory Import Plug-in
3. Click the Plug-in Type drop-down box and select a type.
4. Click the Manufacturer field and enter a name.
5. Click the Model name and enter a name.
6. Click Finish.
An empty Tcl file opens, enabling you to write the logic for the specific plug-in.
Validating CSV Resource Data
To validate CSV resource data, right-click in the CSV editor, and select Validate.
Note The Validate menu is only enabled when there are no validation errors.
Figure 5-26 and Figure 5-27 (same image, but portioned in each figure to show its entirety) displays an
example of an error on Validate invocation.
Note the following characteristics:
• The Outline view with error (red)
• The red marker on the right (red square)
• For each error, a simple marker on the right margin; when mousing over the red marker, see the error
detail in a pop-up prompt.
