Table 5-11 Component Location Generator Properties
Property Name Property Description
Configuration File Property Name
comp.location.gen.info.file
Default File Name complocgenerator.tcl
File format The default
complocgenertator.tcl file is placed under
<MYSERVER_PATH>/lux/inventoryimport/plugindata.
Importing Inventory
5-44 Active System Manager User Guide, Release 7.1
• Resource Location Generator—The Tcl file for generating locations for a resource. This can be changed
as per component manufacturer or model information. Table 5-12 lists the resource location generator
file properties.
Table 5-12 Resource Location Generator File Properties
Property Name Property Description
Configuration File Property Name
dev.location.gen.info.file
Default File Name
resourcelocgenerator.tcl
File format The default resourcelocgenertator.tcl file is placed under
<MYSERVER_PATH>/lux/inventoryimport/plugindata.
• Non-traffic interface location generator—This CSV file compiles the non-traffic interfaces (slot
locations) for a particular manufacturer or model. Table 5-13 lists the non-traffic interface location
generator file properties.
Table 5-13 Non-Traffic Interface Location Generator File Properties
Property Name Property Description
Configuration File Property Name
nontraffic.location.info.file
Default File Name
nontrafficinterfacelocinfo.csv
File format CSV file contains multiple rows with three columns for manufacturer, model,
and list of non-traffic interface locations.
The following location generator files are described:
• The icon location generator file retrieves the icon from a specified location for a particular manufacturer
or model. Table 5-14 lists the icon location generator file properties.
Table 5-14 Icon Location Generator File Properties
Property Name Property Description
Configuration File Property Name
icon.information.file
Default File Name
iconlocinfo.csv
File format CSV file contains only one row with two columns.
First column will specify the icon name.
Second column will specify the icon location (absolute path).
