Running Discovery

Inventory Management 5-7

Running Discovery

After configuring discovery, to start resource discovery, perform the following steps:

1. On the Active System Manager menu bar, click Tools > Discovery > Start.

A prompt asks if you wish to start the discovery process.

2. Click OK to start the discovery process.

The discovery process takes some time due to certain factors such as the number of inventories to

discover, network connectivity, bandwidth and system element response time, etc. At the bottom of the

screen, the status displays that the discovery is in progress; see Figure 5-6.

Figure 5-6 Discovery Progress Status

While the discovery process is in progress, you can switch to the Inventory or Operation perspective to

dynamically display the discovered elements; see Figure 5-7.

Figure 5-7 Discovery Report

The report indicates failures (indicated in red) or success for each element.
