Appendix A—Deployment Activities
Verifying Active System Manager Services
To verify that all Active System Manager services are up and running, perform the following
steps:
1. Log in as the user who installed the services.
1. Run the following script to display the current status of all services, including the
Oracle database status:
cd asm-galeforce/gf/sbin
./asmstatus.sh
Below is sample output:
Active System Manager Services Status
Installation
----------------
Release Version: 7.0
Build Number: 21286
Database
----------------
Vendor: Oracle (Ver: 11.2.0.1.0)
Host: asm-galeforce Port: 1521
Service name: DB11G
Status: Running
Active System Manager Service
----------------------------------
Host: asm-galeforce Port: 40500 Secure Port: 50500
Enterprise: Dell
Lab: DEMO
Status: Running
Domain Services
----------------
1. Domain : System (Id: 1)
Description:
------------------------------------------------------
Session server
Host: asm-galeforce Port: 40500 Secure Port: 50500
Status: Running
