74
Resource Allocation by Groups Report Figure 26.
Top Ten Resource Allocation Report
This report includes three sub-options for different groupings:
• By Host—Lists top ten hosts which are currently in use and have allocated maximum
CPU and memory attributes.
• By User—Displays the list of top 10 users who are currently consuming the maximum
number of CPUs and memory.
• By Group—Similar to “By User”, but consolidated at the group level.
Figure 2728 displays an example of a Top Ten Resource Allocation report.
