69
VMware Host view Figure 21.
Table 13. VMware Hosts operations
Operation Description
Add DataStore to Host This method is used to add an existing datastore to a cluster
visible in Operations View.
Apply Host Profile This method is used for applying the specified profile to a
specified Host. While applying the host profile please make sure
both the Hosts physical configuration should be same. User
can not apply the profile having more than one physical NIC to a
host having single NIC.
Create Profile from Host This method is used for creating Host Profile from a specified Hos.
Enter Maintenance Mode This method is used to put the ESX host into maintenance mode.
VM running on the ESX hosts are suspended or migrated based on
the ESX host configuration and passed parameters to this method.
Exit Maintenance Mode This method is used to exit the ESX from maintenance mode and
power on/restore the VMs which are suspended during the 'Enter
Maintenance Mode' operation.
Display Resource
Utilization
This method is used to view the resource utilization of the host.
List Host Datastore This method is used to view datastores on the host.
