68
VMware Clusters view Figure 20.
Table 12. VMware Cluster Operations
Operation Description
Add DataStore to an
existing cluster
This method adds the data store to an existing cluster.
List Cluster Datastore This method lists the datastores on the cluster.
Move Host to Cluster This method moves the host that is present in data center level to
the existing cluster.
VMware Hosts
VMware hosts, along with their attributes, are discovered and populated in the Active
System Manager Operation Center view. This view (Figure 21) enables methods to be
executed on hosts for on demand provisioning, as required.
