47
Following is the mapping of the Default Server Template networks with the networks
configured on the ESXi server
Table 7. Default ESXi Network Mapping
Type of Network
Server Template Network
Name
VMware ESXi Network Mapping
Hypervisor
Management
DefaultHypervisorManagement ESXi Management Network
Public LAN
DefaultWorkload
Virtual Machine Network
Private LAN DefaultvMotionLiveMigration ESXi vMotion Network
• Server Template names should not contain spaces.
• Server Templates for Active System 1000 VMware should have VM NICs with
the names: HypervisorManagement, vMotion, or Workload.
• Attaching more than one Server Profile Template to a physical orchestration
template will cause the physical orchestration to fail.
• In case multiple VM Workload VLANS are required, then use the “Add..” button to
add more. The networks needs to be added with naming convention “Workload-
<VLANID” e.g. Workload-20
Active System Manager does not pick up the workload VLAN based on the VLAN ID
defined in the Network setting. The workload VLANs are randomly picked up based
on the VLAN range defined for the layer 2 switch in the Active System Manager
Inventory System. If a specific workload VLAN ID is needed, it should be specified in
the VLAN Resource Type
Provisioning settings in the physical template.
• All the four networks listed above needs to have unique VLAN ID.
The network names should contain following substring for enabling RA to identify
proper networks
• Hypervisor Management network should contain "HypervisorManagement"
substring.
• Compute Live Migration network should contain "vMotionLiveMigration"
substring.
• Compute Cluster Private network should contain "HyperVClusterPrivate"
substring
• DHCP and static configurations are supported for Hypervisor Management, vMotion
and WorkLoad networks
