46
Ip Address range Figure 6.
In order to configure the existing ip range, select the already configured range and select
“Edit IP Range” button to modify the existing range and save them.
The below table summarizes the list of values that needs to be configured for a network.
Table 6. Values required for configuring network
Entry Details
VLAN ID The vlan ID that configured on the switch for
this network type.
Configure Static IP address ranges For configuring static ip addresses
Gateway (Optional) Gateway ip for this network
Subnet Mask Subnet mask of this network
Primary DNS (Optional) Primary DNS
Secondary DNS (Optional) Secondary DNS (not mandatory)
DNS Suffix (Optional) Domain name
Starting IP Address The starting ip address
Ending IP Address The ending ip address
Configuring Default Server Templates
The AS 1000 Orchestration applies the Server templates to the server at the time of Set-Up.
Refer to the “Server Profile Templates” document for information on configuring the
default templates.
