14
4. Select the appropriate datastore name where VM needs to be hosted.
5. Select the disk format. Thin provisioning is supported and recommended.
6. Select the network name. The VM needs to be mapped to the Hypervisor
Management Network. All the networks (e.g. OOB, Hypervisor Management,
vMotion, iSCSI and VM workloads) are expected to be accessible from the appliance.
7. Table 5 lists the necessary key access credentials to use.
Table 5. Key Access Credentials
VM Access Credentials Username/Password
Active System Manager server installation login delladmin/delladmin
Active System Manager server root root/Dell@123
Active System Manager application admin/admin
Changing Key Access Credentials
Passwords should be changed at the time of deployment. You should change the passwords
before creating or changing any of the software repositories.
1. Stop Active System Manager services:
a. Log in as user delladmin.
b. Execute following commands:
cd $HOME/asm-galeforce/gf/sbin
