3. In the Component Name box, enter the name of the corresponding servers.
4. In the Server Pool box, enter the name of the server pool.
5. In the Host Name box, enter the host name for the corresponding servers.
6. Click Save.
• If you want to add new server component, next to New Component Settings, click New, and perform the following steps:
1. From the Select a Component drop-down list, select a server component.
2. Under Associated Resources, perform one of the following actions:
– When you are adding a new component to a template, if you want to associate the component with all the existing
components, select Associate All resources option.
The new component automatically associated with the existing components.
– When you are adding a new component to a template, if you want to associate the component only with the
selected components, select Associate Selected Resources, and then select the components to associate as
needed.
Based on the component type, specic settings and properties is displayed automatically that are required and can be
edited. For more information specic to component type settings, see Component Types.
When you redeploy an existing service after adding one or more servers, the following states are displayed in the Resources page:
• The state of the existing server resources that are part of the service changes from “Deployed” to ‘Deploying”, and then changes
to “Deployed” after the deployment is complete.
• The state of the new server changes from “Not In Use” to “Pending”. Once the deployment starts, the state changes to
“Deploying”. If the deployment is successful, the state changes to “Deployed”. If the deployment is not successful, the state
changes to “Critical”.
Adding storage to existing service
To add storage components to an existing service:
1. On the Add Storage page, add the storage to the service by following the steps mentioned here:
• If you want to add new storage component, perform the following steps:
1. From the Select a Component drop-down list, select one of the following storage components:
– Compellent
– EqualLogic
– VNX
2. Under Associated Resources, to associate the newly added storage component to the existing components in the
service, select the components to associate.
3. Click Continue.
Based on the component type, specic settings and properties appear automatically that are required and can be
edited. For more information-specic component type settings, see Component Types.
2. Click Save.
Adding Network
You can update workload network using Add Network feature.
1. On the home page, click Services.
2. Select a service for which you want to add a network, in the right pane, click View Details.
