Connection settings matrix
Table 15. Connection settings matrix
Field Name Description
Type Of Directory Service Refers to the type of directory service (currently available, Microsoft Active Directory).
Name Refers to the Active Directory (AD) conguration name as added in ASM. For example:
mydomain
User Name Refers to the AD account that has privileges to search for users. The account name must be
entered using the User Principle Name format. For example: administrator@mydomain.com
Password Refers to the AD server password for the account in the User Name box.
Host Refers to the AD server FQDN host name or IP address. For example: 192.168.0.5
Port Refers to the AD server port. For example: 389
Protocol Refers to the protocol type as Plain or SSL.
For example: Plain
Attribute settings
The Attribute Settings allows you to perform the attribute settings required for adding an Active Directory.
1. Enter the Base DN, Filter, Username Attribute, First Name, Attribute, Last Name Attribute, and the Email Attribute of the
Active Directory that is to be added to ASM.
2. Click Next.
Attribute settings matrix
Table 16. Attribute settings matrix
Field Name Description
Base DN Refers to the Distinguished Name (DN) where the users are searched by ASM. It is the
Distinguished Name (DN) of the starting point for directory server searches.
For example: CN=Users,DC=mydomain,Dc=com
Filter Refers to the lters that enable you to dene search criteria. For example: objectClass=*
User Name Attribute Refers to the Active Directory record attribute that represents the User Name attribute. This
attribute is mapped to ASM User Name attribute. For example: sAMAccountName
First Name Attribute Refers to the Active Directory record attribute that represents First Name. This attribute is
mapped to ASM First Name attribute. For example: givenName
Last Name Attribute Refers to the Active Directory record attribute that represents the Last Name of the user. This
attribute is mapped to ASM Last Name attribute. For example: sn
Email Attribute Refers to the Active Directory record attribute that represents the Email of the user. This attribute
is mapped to ASM Email attribute. For example: mail
