Users Guide

Directory services
The Directory Services option allows you to add, edit or delete an Active Directory using the Directory Services functionality. ASM
can access these active directories to import users.
NOTE: An Active Directory user is authenticated against the specic Active Directory Domain that a user belongs to.
NOTE: While logging in to the ASM software, the Active Directory user is required to rst enter the directory name that a
user belongs to, followed by the username, for example: domain\username.
The Directory Services page displays the following information about the ASM active directories:
• Host IP address
• Name
• Directory Type
From this screen, you can:
• Add a directory service.
• Edit or Delete an existing directory service.
Related links
Deleting a directory service
Editing a directory service
Adding a directory service
To add a Directory Service, congure the following:
• Connection Settings
• Attribute Settings
Connection settings
1. On the home page, click Settings, and then click Users.
2. In the Directory Services tab, click Create.
3. Select the directory service type from the Type of Directory Service drop-down list.
4. Enter the directory service name in the Name box.
5. Enter the User Name, Password, Host, Port and Protocol (Plain or SSL) of the Active Directory that is to be added to ASM.
NOTE: The default Windows port is 389, but see your Active Directory conguration for the specic port used for
your Active Directory. Currently, the only format supported for User Name is <user name>@<domain.com >.
6. Click Next.
Related links
Attribute settings
Connection settings matrix
Attribute settings matrix
Summary
Importing Active Directory Users
