Ethernet Settings
Refer to the left side of the screen for the following LAN Ethernet settings and the Internet protocol (IP) settings for the Dell Wireless
4350 Small Network Access Point:
Setting/Device Information Displayed
AP IP The IP address assigned to the Dell Wireless 4350 Small Network Access Point
LAN MAC The MAC address for the LAN (Ethernet) interface
AP Host Name
The host name for the Dell Wireless 4350 Small Network Access Point (the default is
Del_4350_AP)
Firmware Version
The version number of the firmware currently installed on the Dell Wireless 4350 Small
Network Access Point
Wireless Channel
The radio channel on which the Dell Wireless 4350 Small Network Access Point is
communicating on the air
Network Name
A unique network name that identifies the wireless network. It is also known as SSID
(Service Set Identifer). When a client station tries to connect to the access point, the
user must know the access point's SSID first.
The following buttons appear on the left navigation bar:
Button Action
Release
Releases the IP address that the Dell Wireless 4350 Small Network Access Point has
been assigned from your network's DHCP server. If the access point has been
configured to have a static IP address, clicking Release does not release this IP
address.
Renew
Renews the IP address from your network's DHCP server. If the access point has been
configured to have a static IP address, clicking Renew does not renew the IP address.
