Dispensing Models Service and Installation Manual
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
6
Dish Dispensers — Drop-In
Model
Flange
Diameter
Cutout
Diameter
Dish
Diameter
Voltage
(60Hz, 1Ph) Amps
Nema
Plug
DIS-500 8.37” 7.75” 5.00” N/A N/A N/A
DIS-575 9.12” 8.50” 5.75” N/A N/A N/A
DIS-650 9.87” 9.25” 6.50” N/A N/A N/A
DIS-725 10.62” 10.00” 7.25” N/A N/A N/A
DIS-813 11.50” 10.87” 8.12” N/A N/A N/A
DIS-913 12.50” 11.87” 9.12” N/A N/A N/A
DIS-1013 13.50” 12.87” 10.12” N/A N/A N/A
DIS-1200 15.37” 14.75” 12.00” N/A N/A N/A
DIS-1450 17.88” 17.25” 14.50” N/A N/A N/A
Dish Dispensers — Drop-In/Heated
Model
Flange
Diameter
Cutout
Diameter
Dish
Diameter
Voltage
(60Hz, 1Ph) Amps
Nema
Plug
DIS-500-ET 8.37” 7.75” 5.00” 120 5.5 5-15P
DIS-575-ET 9.12” 8.50” 5.75” 120 5.5 5-15P
DIS-650-ET 9.87” 9.25” 6.50” 120 5.5 5-15P
DIS-725-ET 10.62” 10.00” 7.25” 120 5.5 5-15P
DIS-813-ET 11.50” 10.87” 8.12” 120 5.5 5-15P
DIS-913-ET 12.50” 11.87” 9.12” 120 5.5 5-15P
DIS-1013-ET 13.50” 12.87” 10.12” 120 5.5 5-15P
DIS-1200-ET 15.37” 14.75” 12.00” 120 5.5 5-15P
DIS-1450-ET 17.88” 17.25” 14.50” 120 5.5 5-15P
Dish Dispensers — Drop-In/Heated/Quick Temp
Model
Flange
Diameter
Cutout
Diameter
Dish
Diameter
Voltage
(60Hz, 1Ph) Amps
Nema
Plug
DIS-813-QT 11.50” 10.87” 8.12” 120 5.5 5-15P
DIS-913-QT 12.50” 11.87” 9.12” 120 5.5 5-15P
DIS-1013-QT 13.50” 12.87” 10.12” 120 5.5 5-15P
DIS-1200-QT 15.37” 14.75” 12.00” 120 5.5 5-15P
DIS-1450-QT 17.88” 17.25” 14.50” 120 5.5 5-15P
Disposable Cup Dispensers
Model Flange Diameter Cutout Diameter Dish Diameter
CD 7.38” 5.12” 2.50”-4.63”
Bread Dispensers
Model Flange Diameter Cutout Diameter Bread Dimension Ship Weight
SB-1 6.50” X 6.50” 5.87” X 5.87" 5.25” X 5.25” 15lbs (7kg)
Specifications
