Installation manual

Dispensing Models Service and Installation Manual
5
For customer service, call [phone], [phone], Fax [phone], www.delfield.com
Dish Dispensers — Mobile Two Stack
Model
Max.
Dish
Diameter
Voltage
(60hz,
1Ph) Amps
Nema
Plug
CAB2-500 5.00” N/A N/A N/A
CAB2-575 5.75” N/A N/A N/A
CAB2-650 6.50” N/A N/A N/A
CAB2-725 7.25” N/A N/A N/A
CAB2-813 8.12” N/A N/A N/A
CAB2-913 9.12” N/A N/A N/A
CAB2-1013 10.12” N/A N/A N/A
CAB2-1200 12.00” N/A N/A N/A
CAB2-1450 14.50” N/A N/A N/A
CAB2-500ET 5.00” 120 11.0 5-20P
CAB2-575ET 5.75” 120 11.0 5-20P
CAB2-650ET 6.50” 120 11.0 5-20P
CAB2-725ET 7.25” 120 11.0 5-20P
CAB2-813ET 8.12” 120 11.0 5-20P
CAB2-913ET 9.12” 120 11.0 5-20P
CAB2-1013ET 10.12” 120 11.0 5-20P
CAB2-1200ET 12.00” 120 11.0 5-20P
CAB2-1450ET 14.50” 120 11.0 5-20P
CAB2-813QT 8.12” 120 11.0 5-20P
CAB2-913QT 9.12” 120 11.0 5-20P
CAB2-1013QT 10.12” 120 11.0 5-20P
CAB2-1200QT 12.00” 120 11.0 5-20P
CAB2-1450QT 14.50” 120 11.0 5-20P
Dish Dispensers — Mobile Three Stack
Model
Max.
Dish
Diameter
Voltage
(60hz,
1Ph) Amps
Nema
Plug
CAB3-500 5.00” N/A N/A N/A
CAB3-575 5.75” N/A N/A N/A
CAB3-650 6.50” N/A N/A N/A
CAB3-725 7.25” N/A N/A N/A
CAB3-813 8.12” N/A N/A N/A
CAB3-913 9.12” N/A N/A N/A
CAB3-1013 10.12” N/A N/A N/A
CAB3-1200 12.00” N/A N/A N/A
CAB3-1450 14.50” N/A N/A N/A
CAB3-500ET 5.00” 208 10.6 6-20P
CAB3-575ET 5.75” 208 10.6 6-20P
CAB3-650ET 6.50” 208 10.6 6-20P
CAB3-725ET 7.25” 208 10.6 6-20P
CAB3-813ET 8.12” 208 10.6 6-20P
CAB3-913ET 9.12” 208 10.6 6-20P
CAB3-1013ET 10.12” 208 10.6 6-20P
CAB3-1200ET 12.00” 208 10.6 6-20P
CAB3-1450ET 14.50” 208 10.6 6-20P
CAB3-813QT 8.12” 208 10.6 6-20P
CAB3-913QT 9.12” 208 10.6 6-20P
CAB3-1013QT 10.12” 208 10.6 6-20P
CAB3-1200QT 12.00” 208 10.6 6-20P
CAB3-1450QT 14.50” 208 10.6 6-20P
Dish Dispensers — Mobile Four Stack
Model
Max.
Dish
Diameter
Voltage
(60hz,
1Ph) Amps
Nema
Plug
CAB4-500 5.00” N/A N/A N/A
CAB4-575 5.75” N/A N/A N/A
CAB4-650 6.50” N/A N/A N/A
CAB4-725 7.25” N/A N/A N/A
CAB4-813 8.12” N/A N/A N/A
CAB4-913 9.12” N/A N/A N/A
CAB4-1013 10.12” N/A N/A N/A
CAB4-1200 12.00” N/A N/A N/A
CAB4-1450 14.50” N/A N/A N/A
CAB4-500ET 5.00” 208 14.2 6-20P
CAB4-575ET 5.75” 208 14.2 6-20P
CAB4-650ET 6.50” 208 14.2 6-20P
CAB4-725ET 7.25” 208 14.2 6-20P
CAB4-813ET 8.12” 208 14.2 6-20P
CAB4-913ET 9.12” 208 14.2 6-20P
CAB4-1013ET 10.12” 208 14.2 6-20P
CAB4-1200ET 12.00” 208 14.2 6-20P
CAB4-1450ET 14.50” 208 14.2 6-20P
CAB4-813QT 8.12” 208 14.2 6-20P
CAB4-913QT 9.12” 208 14.2 6-20P
CAB4-1013QT 10.12” 208 14.2 6-20P
CAB4-1200QT 12.00” 208 14.2 6-20P
CAB4-1450QT 14.50” 208 14.2 6-20P
Specifications
