Replacement Parts List, continued
Model CT Series
6230068 Bearing
6230170 Bumper, corner, small
3234180 Caster, 4”
6150206 Extension spring
CT-1216
000-BLD-0030 Carrier assembly, 12.50 x 16.50
CT-1221
000-BLD-0031 Carrier assembly, 12.50 x 21.50
CT-1418
000-BLD-0032 Carrier assembly, 14.56 x 18.56
CT-1422
000-BLD-0033 Carrier assembly, 14.50 x 22.50
CT-1622
000-BLD-0034 Carrier assembly, 16.56 x 22.56
CT-1826
000-BLD-0035 Carrier 18.56 x 26.56
CT-2020
000-BLD-0036 Carrier assembly, 20.56 x 21.56
Model FT2-SN All units
6320007 Bearing
6230218 Caster, 4”
6230170 Corner bumper
000-546-0038 Elevator assembly, large
6150203 Extension spring .16
6150202 Extension spring .28
6150201 Extension spring .58
6230024 Silverware container, Plastic
3234052 Silverware container, S/S
FT2-SN-1216
372-395-0030 Carrier 1216
FT2-SN-1418
372-395-0032 Carrier, 1418
FT2-SN-1622
372-395-0035 Carrier 1622
Model T & T2 Series
T-1014, All T2 Models
6320007 Bearing, 0.50”ID
3234180 Caster, 4”, Swivel, with Break
6150201 Spring, Extension, 0.58lbs/In
T-1216 through T-2020
6320007 Bearing, 0.50”ID
3234180 Caster, 4”, Swivel, with Break
6150202 Spring, Extension, 0.28lbs/In
Model LT & LT2 Series
LT-1014, All LT2 Models
6320007 Bearing, 0.50”ID
6150201 Spring, Extension, 0.58lbs/in
LT-1216 through LT-2020
6320007 Bearing, 0.50”ID
6150202 Spring, Extension, 0.28lbs/in
Model T-H & T2-H Series
All Models
6320007 Bearing, 0.50”ID
6160007 Blade, Fan 4”Dia, Alum
3234180 Caster, 4”, Plate, Swivel, Break
6190269 Element, Heating, 120V/700W
6160024 Motor, 115V, 50/60Hz
6190180 Switch, Hi-limit, 245F
2190154 Switch, Rocker, 20A/125V, 15A/250V
6190181 Thermostat
T-1221H, T-1418H
2183348 Cord Assembly, 14/3 W/Nema 5-15P
T-1422H, T-1826H, T-2020H, T2-1221H
2183347 Cord Assembly, 12/3 W/Nema 5-20P
All T-H Models
6150202 Spring, Extension, 0.28lbs/in
T2-1221H
6150201 Spring, Extension, 0.58lbs/in
Model TT Series
All Models
6320007 Bearing, 0.50”ID
6230218 Caster, 4”, Stem, Swivel Break
6150201 Spring, Extension, 0.58lbs/in
