Dispensing Models Service and Installation Manual
17
For customer service, call (800) 733-8829, (800) 773-8821, Fax (989) 773-3210, www.delfield.com
Models DIS
All units
6230314 Filter, air, 6” diameter (DDS)
6230244 Guide post
6150201 Spring, heavy tension
6150203 Spring, light tension
6150202 Spring, medium tension
500 units
6200121 Spinning head
6970011 Wire head
575 units
6200122 Spinning head
6970012 Wire head
650 units
6200123 Spinning head
6970013 Wire head
725 units
6200124 Spinning head
6970014 Wire head
813 units
6200125 Spinning head
6970015 Wire head
913 units
6200126 Spinning head
6970016 Wire head
1013 units
6200127 Spinning head
6970017 Wire head
1200 units
6200128 Spinning head
6970018 Wire head
1450 units
6200129 Spinning head
6970026 Wire head
Model DIS-ET, DIS-QT
All units
6190085 Cord with plug, NEMA 5-15P 5’
6230314 Filter, air, 6” diameter
6230244 Guide post
6160024 Motor, 115V 50-60Hz
6150201 Spring, heavy tension
6150203 Spring, light tension
6150202 Spring, medium tension
6190180 Switch, high-limit, 245°F
2190154 Switch rocker
6190181
T-stat, automatic 165°F - 205°F
500/ 575/ 650/ 725 ET units
6160008 Fan blade, 3” diameter
6190250 Heating element, 120V/327W
000-BHM-0030
Heating module
813/ 913/ 1013/ 1200/ 1450 ET & QT
units
6160007 Fan blade, 4” dia, ET &QT
6190269
Htg element, 120V/700W,
ET &
QT
000-BHM-0031
Heating module, ET & QT models
Model CAB, CAB-ET,
CAB-QT
All units
3234180 Caster, 4” with brake
6190085 Cord with plug, NEMA 5-15P 5’
6230314 Filter, air, 6” diameter
6230244 Guide post
6160024 Motor, 115V 50-60Hz
6150203 Spring, light tension
6150202 Spring, medium tension
6190180 Switch, high-limit, 245°F
2190154 Switch rocker
6190181 T-stat, automatic 165°F - 205°F
500/ 575/ 650/ 725 ET units
6160008 Fan blade, 3” diameter
6190250 Heating element, 120V/327W
000-BHM-0030
Heating module
813/ 913/ 1013/ 1200/ 1450 ET & QT
units
6160007 Fan blade, 4” dia, ET &QT models
6190269
Htg element, 120V/700W,
ET &
QT
000-BHM-0031
Heating module, ET & QT models
CAB2-ET & CAB2-QT units
2183347 Cord with plug, NEMA 5-20P 9’
CAB3-ET, CAB4-ET, CAB3-QT, CAB4-QT
units
6190079 Cord with plug, NEMA 6-20P 9’
Model SB
6150024 Dish spring
Model ND
ND-45
223-BGA-0030
Cover
6150203 Extension spring
313-B38-0030 Head
ND-47
223-BGA-0031
Cover
6150203 Extension spring
313-B38-0031 Head
ND-48
223-BGA-0032
Cover
6150203 Extension spring
313-B38-0032 Head
ND-57
223-BGA-0033 Cover
6150203 Extension spring
313-B38-0033 Head
ND-59
223-BGA-0034 Cover
6150203 Extension spring
313-B38-0034 Head
ND-67
223-BGA-0035 Cover
6150203 Extension spring
313-B38-0035 Head
Replacement Parts List
