User's Manual

ENVIRONMENTAL CONDITIONS:
The unit is designed for indoor applications:
Operating temperature
- 30
°
C to + 50
°
C
Storage temperature
- 50
°
C to + 80
°
C
MECHANICAL SPECIFICATIONS:
Size 10 x 10 x 5 inch approx.
(250 x 250 x 120 mm approx.)
RF Connectors N-type Female
Weight
15 Lbs. (7 kg.) approx.
RF EXPOSURE WARNING
In order to satisfy the FCC RF exposure requirements, you must ensure that the installation complies
with the following:
One antenna is connected via cable that has typical 1~10 dB attenuation (depends on the length of the
cable) to the BDA BASE port. This antenna is installed outdoor and has very sharp beam (Yagi type or
similar) pointed to the donor (BTS). This type of antenna has about 10 dBi gain. Typical specifications:
gain: 8 dBd (=10.1 dBi), VSWR: better than 1.5:1 , Impedance: 50 ohm. The outdoor antenna must be
installed to provide a minimum separation distance of 0.3 m (30 cm) from persons within the area.
The second antenna is connected via cable that has typical 1~10 dB attenuation (depends on the length
of the cable) to the CBDA MOBILE port. This type of antenna is omnidirecttional (isotropic), or wide
beam, with 0 to 2 dBi typical gain and is installed and distributes indoor (in buildings, tunnels,
basements, park lots, shopping centers etc.). Typical specifications: gain: 2 dBi, VSWR: better than 2:1 ,
Impedance: 50 ohm. The indoor antenna must be installed to provide a minimum separation distance of
0.2 m (20 cm) from persons within the area.
