6. Specifications
6.1. Electrical specifications
Specification Parameter
Downlink Uplink
Frequency Range [MHz] See table below See table below
Gain [dB] 90±4
Passband ripple <3dB p-p
Attenuation range (via |SW) 0 to 31dB in 1dB steps
Noise figure ≤ 5dB
Output power @ 1dB compression 50W 8W
3
rd
order intercept point 62 dBm min 47 dBm typ.
Composite power output +40dBm +27dBm
Downlink IMD @ two tone 37dBm each 50dBc --------------------
Uplink IMD @ two tone
24dBm each
------------------- 44dBc
ALC factory set level (nom.) 40dBm 27dBm
ALC range 15dB 20dB
Impedance
50
Ω
VSWR <1.5:1
Rx/Tx isolation > 100dB
Power supply AC 110/220V/50Hz Range: 176~264V, 45~65
System frequency range
BLOCK Model No. Down Link Up Link
A MW-BDA-PCS-A-50W90 1930-1945 1850-1865
D MW-BDA-PCS-D-50W90 1945-1950 1865-1870
B MW-BDA-PCS-B-50W90 1950-1965 1870-1885
E MW-BDA-PCS-E-50W90 1965-1970 1885-1890
F MW-BDA-PCS-F-50W90 1970-1975 1890-1895
C MW-BDA-PCS-C-50W90 1970-1975 1895-1910
AD MW-BDA-PCS-AD-50W90 1930-1950 1850-1870
BE MW-BDA-PCS-BE-50W90 1950-1970 1870-1890
DBE MW-BDA-PCS-DBE-50W90 1945-1970 1865-1890
EFC MW-BDA-PCS-EFC-50W90 1965-1990 1885-1910
6.2. Mechanical specifications
Size [mm] 600X400X300 (approx.)
RF connectors N-type Female
Weight [Kg] 40 (approx.)
Enclosure Type Weatherproof enclosure for wall-mounted
installation
