2.5.1.2. Relay outputs
2.5.1.2.1. Overview screen
The figure shows two modules next to each other with corresponding
numbering of the terminal blocks.
The lower figure shows a flexible conntector module with 32 outputs and
corresponding numbered ports. Each outer end of the module has a 26 pol. wire
trap connector. Thus, multiple modules can be connected in series using a
ribbon cable for each connection.
