Hardware description |
Seite 29
2.2.1.2. Technical data
Single power supply +7V..+24V DC
7 control LEDs
CAN 2.0A (11 Bit addressing)
CAN 2.0B (29 Bit addressing)
Transmission range up to 10km (at 10Kbit/s)
Easy to configure over DIP switches
Galvanically isolated interface using optocouplers
9 pol. D-SUB socket
Timeout feature providing ability to disconnect outputs for safety reasons
Comfortable connector system with ejection mechanism
Expandable in 16 gradations
Can be combined without any problem to other modules of the RO series
