DMON‐6SHardwareManualforFirmwareVersion1.1
Copyright©2014DecimatorDesignPtyLtd,Sydney,Australia
14
3.SETUP/BACK2STATUSTIME(Parameter)
ThisisthetimebeforethemainmenuisreturnedtoInputStatusafterthelastbuttonpress.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingtimes:
1.) 5seconds
2.) 15seconds
3.) 30seconds
4.) 1minute
5.) 5minutes

4.SETUP/AUTOSAVE(Parameter)
Thisparameterwilldetermineifanychangeswillbesavedtomemorywhenchangesaremade.
Whenthesubmenuishighlighted,pressENTERtotogglethroughthefollowingselections:
3.) Yes
4.) No

5.SETUP/DemoCycle(Parameter)
TheDemocyclesettingisusedforcyclingthroughmultiplelayouts,windowsorinputsonatimedelay.When
thesubmenuishighlighted,presstheENTERbuttontoenterthissub‐menu.
Pressthe<and>buttonstomoveleftorrightthroughthefollowingcycletypes:
1.) None
2.) OutputSelect
3.) MVWindows
4.) MVLayouts

Note:Theparameterwillonlybeupdatedwhenleavingthissub‐menu.

6.SETUP/DemoCycleTime(Parameter)
TheDemoCycleTimedeterminestheamountoftimetoelapsebeforecyclingtothenextitem.Whenthesub
menuishighlighted,presstheENTERbuttontoenterthissub‐menu.
Pressthe<and>buttonstomoveleftorrightthroughthetimeuntiltheunitmovesto
thenextiteminthe
cycle.
Defaulttimeis10Seconds,Maximumtimeis256Seconds

Note:Theparameterwillonlybeupdatedwhenleavingthissub‐menu.


GPIPINS

PIN1=Ground PIN14 = Window5 TallyRed PIN27 = Window6TallyRed
PIN2=RS485+ PIN15 = Window1 Select PIN28 = Window2TallyBlue
PIN3=Window1TallyGreen PIN16 = Window3 Select PIN29 = Window4TallyBlue
PIN4=Window3TallyGreen PIN17 = Window5 Select PIN30 = Window6TallyBlue
PIN5=Window5TallyGreen PIN18 = Multi‐ViewSelect PIN31 = Window2TallyYellow
PIN6=Window1TallyRed PIN19 = Ground PIN32 = Window4TallyYellow
PIN7=Window3TallyRed PIN20 = Ground PIN33 = Window6TallyYellow
PIN8=Window5TallyRed PIN21 = RS485‐ PIN34 = Window2Select
PIN9=Window1TallyBlue PIN22 = Window2 TallyGreen PIN35 = Window4Select
PIN10=Window3TallyBlue PIN23 = Window4 TallyGreen PIN36 = Window6Select
PIN11=Window5TallyBlue PIN24 = Window6 TallyGreen PIN37 = OutputSelectToggle
PIN12=Window1TallyYellow PIN25 = Window2 TallyRed
PIN13=Window3TallyYellow PIN26 = Window4 TallyRed


