Owner's manual

User level - Menu #MEASURES
Parameter Description Unit
OUTSIDE TEMP.
Outside temperature °C
ROOMTEMP. A
(1)
Room temperature of circuit A °C
ROOMTEMP. B
(1)
Room temperature of circuit B °C
ROOMTEMP. C
(1)
Room temperature of circuit C °C
BOILER TEMP.
Water temperature in the boiler °C
PRESSURE
Water pressure in the installation bar
WATER TEMP.
(1)
Water temperature in the DHW tank °C
INST DWH TEMP.
(1)
Instant hot water temperature °C
STOR.TANK.TEMP
(1)
Water temperature in the storage tank °C
DCW TEMPERATURE
Domestic cold water temperature °C
SWIMMING P.T.B
(1)
Water temperature of the swimming pool on circuit B °C
SWIMMING P.T.C
(1)
Water temperature of the swimming pool on circuit C °C
OUTLET TEMP. B
(1)
Temperature of the flow water in circuit B °C
OUTLET TEMP. C
(1)
Temperature of the flow water in circuit C °C
SYSTEM TEMP.
(1)
Temperature of the system flow water if multi-generator °C
T.DHW BOTTOM
(1)
Water temperature in the bottom of the DHW tank °C
TEMP.TANK AUX
(1)
Water temperature in the second DHW tank connected to the AUX circuit °C
DHW A TEMP.
(1)
Water temperature in the second DHW tank connected to circuit A °C
BACK TEMP Temperature of the boiler return water °C
WIND SPEED Fan rotation speed rpm
POWER Instantaneous boiler output (0%: Burner off or running at minimum output) %
CURRENT (µA) Ionization current µA
NB IMPULS. Number of burner starts (not restartable)
The meter is incremented by 8 every 8 start-ups
RUNTIME Number of burner operation hours (not restartable)
The meter is incremented by 2 every 2 hours
h
IN 0-10V
(1)
Voltage at input 0-10 V V
SEQUENCE
Control system sequence
CTRL Software control number
(1) The parameter is only displayed for the options, circuits or sensors actually connected.
