Verdi will show the warning messages Caution and Loud in the main display
for 20 seconds and then the burn-in signal will ramp-up from zero to maximum
level over a period of about 10 seconds.
The display cycles through Burn in, Caution and Loud while the Burn In
routine is running.
do this: To stop the Burn-in signal, press either a
Step or Select button once. The
display will briefly show:
Done
Test
TestTest
Test - Display Test
This runs a test routine to ensure the display is working correctly.
do this: Open the Menu and step through until the display shows Test.
do this: Press the
Select button once to start the test.
• The main display lights up then fades from bottom to top.
• The indicator LEDs light up briefly in sequence.
• All indicators light up, along with small squares on the main display. This
flashes off and on once.
• The display shows Done.
Issue
IssueIssue
Issue – Software Issue State
This displays the issue number of the software fitted to your unit. You will need
to check this if you are considering a software upgrade or if your unit
malfunctions.
do this: Open the Menu and step through until the display shows Issue.
do this: Press the
Select button once to display the software issue.
do this: For units fitted with a 1394 interface, press the
Select button again to display
the 1394 interface software issue.
Temp
TempTemp
Temp – Unit Internal Temperature
This displays the temperature inside the unit, close to the crystal oscillators.
do this: Open the Menu and page through until the display shows Temp.
do this: Press the
Select button once to display the temperature in degrees Fahrenheit.
Press
Select again to change to degrees Celsius.
Serial
SerialSerial
Serial – Unit Serial Number
This displays the full serial number, including the hardware configuration code.
We will need this information to assemble upgraded software to suit your unit.
do this: Have a pen and paper handy to note down the number. Open the Menu and
step through until the display shows Serial.
do this: Press the
Select button once and the serial number will scroll across the
display.
Contact
ContactContact
Contact - Contact information
This displays dCS’ email address and web-site URL.
do this: Open the Menu and step through until the display shows Contact.
do this: Press the
Select button once and the contact information will scroll across the
display.
