Ph.Check
Ph.CheckPh.Check
Ph.Check - Phase Check Test
Use this feature to check if one channel in your system is phase inverted
4
. It is
disabled when in DSD/SACD mode.
do this: Set up your system to play music at a comfortable level.
do this: Open the Menu and step through until the display shows:
Ph.Check
do this: Press the Select button once to start the test.
After briefly displaying Wait, the following sequence occurs:
Normal
In-phase noise appears on both channels for several seconds.
None
Both outputs are muted for a second.
Inverted
A second burst of noise appears on both channels with the right channel
inverted for several seconds.
Done
This is displayed briefly at the end of the test.
If both channels are in-phase the first burst of noise will produce a stable central
image but the second burst will not. If one channel is out of phase, the second
burst will produce a stable stereo image but the first will not.
If there is a phasing error, check for wiring errors from the unit output onwards.
You cannot correct this error on a dCS DAC using the Phase feature as this
inverts both channels.
Burn In
Burn InBurn In
Burn In - Burn-In Signal Generation
IMPORTANT! Read all the steps in this section before starting the System Burn-in routine.
The Burn-in routine outputs a signal at maximum volume.
IMPORTANT! This routine is NOT suitable for burning-in loudspeakers. Ensure your
loudspeakers are disconnected, or your power amplifier is switched off
before starting this routine.
Use this feature to burn-in your system components with modulated pink noise.
It is disabled when in DSD/SACD mode.
do this: Set up your system volume control to the usual setting.
do this: Open the Menu and step through until the display shows:
Burn In
do this: Press the Select button once to start the burn-in routine.
4
The ear responds to positive pressure substantially more than it does to negative pressure for low
frequencies, so it is worth getting the phasing correct.
