Bright x
Bright xBright x
Bright x - Display Brightness
This adjusts the brightness of the main display, with settings between 7
(brightest) and 0 (off, unless something is touched).
do this: Open the Menu and step through until the display shows Bright x, where x is a
number between 7 and 0.
do this: Press the
Select button repeatedly and the display cycles through Bright 7,
Bright 6, ......., Bright 1, Bright 0 and back to Bright 7.
After time-out, a setting of Bright 0 blanks the display unless the unit is not
locked. Operating any control or locking to a source while in this mode turns the
display back on momentarily.
TimeOut
TimeOutTimeOut
TimeOut – Menu Time Out Setting
If you find the 5 second time out period for the menu is too short, use this option
to change the time out period to 30 seconds.
do this: Open the Menu and step through until the display shows Timeout.
do this: Press the
Select button once and the display will show Normal.
do this: Press the
Select button again and the display will change to Long.
do this: Repeat this if you want to change back.
Ch.Check
Ch.CheckCh.Check
Ch.Check - Channel Check Test
Use this feature to check if the stereo outputs on your system are swapped. It is
disabled when in DSD/SACD mode.
do this: Set up your system to play music at a comfortable level.
do this: Open the Menu and step through until the display shows:
Ch.Check
do this: Press the Select button once to start the test. After briefly displaying Wait, the
following sequence occurs:
Left
A modulated tone should appear on the left channel only for several seconds.
None
Both outputs are muted for a second.
Right
A modulated tone should appear on the right channel only for several seconds.
Done
This is displayed briefly at the end of the test.
If the channels are swapped, check for wiring errors from the unit output
onwards. If you correct this temporarily using the Swap function on a dCS DAC,
note that the Swap setting is NOT remembered at power down.
