The hardware shown here is provided for assembly and mounting:
Additional Components on Vantage Pro Plus
Vantage Pro Plus includes an ultraviolet (UV) sen-
sor and a solar radiation sensor. These two sensors
are on the rain collector side of your ISS.
Note: Please make every effort when handling your ISS not to touch
the small white diffusers on top of the UV and solar radiation
sensors. Oil from the skin will reduce their sensitivity. Clean the
diffusers using ethyl alcohol on a soft cloth (NOT rubbing alco-
hol).
Tools for Installation
Refer to this section in your ISS Installation Manual.
Preparing the Anemometer
Refer to this section in your ISS Installation Manual.
Disassembling the Radiation Shield
The radiation shield must be disassembled in order to make necessary cable
connections and to install batteries in the wireless version of the ISS, which is
solar powered.
1/4" Flat Washers
1/4" Lock Washers
1/4" Hex Nuts
U-Bolts
Nut Plate
.05"
Allen Wrench
1/4" x 3" Lag Screws
#4 x 1-1/8"
Machine Screw
#4 Tooth
Lock Washer
#4 Flat
Washer
#4-40
Hex Nut
Vantage Pro Plus ISS
