User Guide

9
Wireless Vantage Pro2
™
Sensor Charts
Temperature Accuracy
0.0
1.0
2.0
3.0
4.0
5.0
-40 -20 0 20 40 60 80 100 120 140
Temperature (°F)
Temperature Accuracy
0.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
4.5
5.0
-40 -30 -20 -10 0 10 20 30 40 50 60
Temperature (°C)
Accuracy (°F) Accuracy (°C)
Figure 1. Temperature Accuracy
Rain Rate Resolution
Low Range
Resolution (in.)
10.0
1.00
0.10
0.01
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Rain Rate (in/hr.)
Rain Rate Resolution
Full Range
Resolution (in.)
100.00
10.00
1.00
0.10
0.01
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Rain Rate (in/hr.)
Figure 2. Low Range Rain Rate Resolution
Figure 3. Full Range Rain Rate Resolution
