12. Technical Specifications

ELECTRICAL

Power Requirements 11-30VDC (10A max., depending on system configuration)

Power Distribution Power-over-Ethernet (802.3af)

Radio Connectivity See U9102 or U9104

Auxilliary Connectivity See U9102

System Cable Type CAT5e (stock) or CAT6

Intercom Connection Scheme RJ-45 type

MECHANICAL

Mounting Method (where applicable) Surface (included) or Flush/Rack Mount Kits (optional)

Enclosure Material (where applicable) Polyethylene

COMPLIANCE

MECHANICAL

Ingress Protection IP67, per IEC 60529, with proper installation

Operating Temperature* -40° to +185°F (-40° to +85°C), per MIL-STD-810G

Storage Temperature* -40° to +158°F (-40° to +70°C), per MIL-STD-810G

Aggravated Humidity Per MIL-STD-810G

Functional Shock Per MIL-STD-810G

Operational Vibration Per MIL-STD-810G

Salt Fog Per MIL-STD-810G

ELECTRICAL (WIRED)

Immunity to DC Power Line Transients Per EN 301 489-1 (ISO 7637-2)

Radiated and Conducted Emissions Per EN 301 489-1, FCC Part 15

Electrostatic Discharge Per EN 301 489-1

Radiated Immunity Per EN 301 489-1

Electrical Fast Transient Burst Per EN 301 489-1

Conducted Immunity Per EN 301 489-1

ELECTRICAL (WIRELESS)

Specific Absorption Rate (SAR) Compliance

Per IEEE 1528-2003, OET Bulletin 65, RSS-102 & Safety

Code 6

DECT Harmonized EN Per EN 301 406

EMC & ERM, Short Range Devices Per EN 300 330-1, EN 300 330-2

Electrostatic Discharge Per EN 61000-4-2

Radiated Immunity Per EN 61000-4-3

EMC & ERM for Radio Equipment and Services, Part 1 Per EN 301 489-1

EMC & ERM for Radio Equipment and Services, Part 6 Per EN 301 489-6

CB Scheme Per IEC 60950

* Not applicable to Wireless Belt Stations or Battery Charger

See individual product Data Sheets for more information

Table 12.1 Technical Specifications
