User's Manual

9. Testing & Troubleshooting

Parts/Tools Required

 Completion of the previous installation sections in their entirety

 An assistant (recommended)

Test Procedure

 Double-check all connections and wiring from the previous sections.

 Complete connections of power cables to power source.

 Turn on power at the pick-off point/source.

 Connect a computer/laptop via Ethernet cable to one of the switch card ports on the Master

Station.

o If all switch card ports are used, a PoE splitter such as CyberData #011187 or a PoE

capable Ethernet switch may be used.

 After approximately 30 seconds, open a web browser and go to http://192.168.2.1

 Once the system initializes, click DEVICE MANAGEMENT

 Verify that all installed devices are present on this list, including add-in cards.

 To test audio and radio/aux connections, see 8. Operation and Programming.

Troubleshooting

If the system does not function properly, it can be reset by either powering off the Series 9100 Digital

Intercom System and then powering it back on.

Most problems are a result of improper setup. The first step in troubleshooting should always be to

perform the SETUP WIZARD again.
