Talk Group Example 3: Multiple users on hot-mic intercom, press PTT to talk over radio
• Multiple users talking to each other freely (no PTT)
• Press PTT to talk over radio
• Selection may be anything (1-4)
Steps
1. Create a new talk group and rename it “Intercom”
2. Click to expand each Headset or Wireless user you wish to add to this group.
3. Under Outputs select All Rx. For wireless, select Ear.
4. Under Inputs select Mic.
5. Create another new talk group and rename it “Radio”
6. Click to expand each Headset or Wireless user to configured in the “Intercom” talk group.
7. Under Outputs select All Rx. For wireless, select Ear.
8. Under Inputs select Mic-PTT.
9. Click to expand the Radio card or Radio/Aux card
10. Under Radio 1 Outputs select Radio Tx.
11. Under Radio 1 Inputs select Radio Rx.
12. Click SAVE REQUIRED.
13. When the operation is complete, users of this group are now able to talk to each other freely,
and pressing the PTT button on the Headset Station, Wireless Belt Station, or the headset
mic boom will cause that user to transmit over the radio.
14. See Figures 8.14 and 8.15.
