The U9120-series Wireless Gateways provide an un-tethered interface into the U9100 Digital Intercom
System. Each Wireless Gateway can be linked with up to four U91xxBSW belt stations. The Wireless
Gateway has the following interfaces:
• Link button
o Used to link Wireless Belt Stations
• Antenna connector (RP-SMA)
o For optional externally mounted antenna
• Ethernet Jack (RJ45)
o Provides communications and power to the Wireless Gateway
Figure 8.2 Wireless Gateway
