10 QuickScan
TM
i
USB Interface
The imager attaches directly to a USB host, or a powered USB
hub, and is powered by it. No additional power supply is re-
quired. When using a USB interface, the imager auto-detects
the USB and defaults to the HID keyboard interface.
Select USB-COM-STD
1
(simulates RS-232 standard interface)
Select USB Keyboard (with standard key encoding)
Select USB Alternate Keyboard (with alternate key encoding)
Select USB OEM
Select USB-KBD-APPLE (for Apple computers)
1. Download the correct USB Com driver from www.datalogic.com.
