1 MEMOR™ X3
110
5
READING OPTIONS
LINEAR IMAGER CHARACTERISTICS
SCANNING RATE 50 scan/sec nominal
OPTICAL RESOLUTION 5 mil (minimum readable bar code module size)
DEPTH OF FIELD See reading diagrams
SKEW ANGLE ± 50°
PITCH ANGLE ± 65°
BAR CODES
GS1 DataBar family, EAN/UPC, Code 39, 2/5
Codes, MSI, Codabar, Code 128, GS1-128, Code
93, Code 11, Pharmacode 39, Trioptic
LASER CLASSIFICATION
Laser: Class 2
Safety class: N 60825-1:2001
LED CLASSIFICATION Led (Illuminator): Class 1M
ILLUMINATION SYSTEM LEDs 620~630 nm
