TECHNICAL FEATURES
109
5
READING OPTIONS
IMAGER CHARACTERISTICS
SCANNING RATE 60 frames/sec
OPTICAL RESOLUTION 0.13 mm / 5 mils
AIMING LASER VLD, wavelength 645~665 nm
BAR CODES
Decoded barcodes 1D:
UPC A, UPC E, EAN 8, EAN 13, Interleaved 2 of
5, Codabar, Code 11,
Code 39, Code 39 Full
ASCII, Code 93, Code 128, EAN 128, GS1
Databar, MSI, Matrix 2 of 5, Standard 2 of 5,
Plessey
Decoded barcodes 2D:
PDF417, DataMatrix, QR, MicroPDF, RSS,
Maxicode, Aztec
Postal codes:
PostNet, Planet, UK Postal, Japan Postal,
Australia Postal, Ducth Postal, USPS, UPU
, UK
Check TX, US Check TX
LASER CLASSIFICATION
Laser: Class 2
Safety class: N 60825-1:2001
LED CLASSIFICATION Led (Illuminator): Class 1M
ILLUMINATION SYSTEM LEDs 620~630 nm
