User manual

GRYPHON™ Dx30/Mx30
6
6.4 SYSTEM AND RADIO FEATURES
Radio Features
Working Frequency 433.92 MHz
Bit Rate 19200
Effective Radiated Power <10 mW
Range (in open air) 30 m
RF Modulation FSK
System Configurations
OM-GRYPHON™ STARGATE™
Maximum number of devices per
base stations
16 255
Maximum number of devices in the
same reading area
2000
Maximum number of base stations
in network
16
6.5 STATUS INDICATORS
The reader has three indicators, LED, Beeper and Good Read Spot. The
OM-Gryphon™ and C-Gryphon™ cradles have three indicator LEDs. They signal
several operating conditions which are described in the tables below.
H = high tone L = low tone
GRYPHON™ Dx30/Mx30 READER START-UP
Beeper¹
Meaning
L L L L Parameters loaded correctly
H H H H
long tones
Parameter loading error, reading or writing error in the non volatile
memory
H L H L Hardware error in EEPROM
GRYPHON™ Dx30/Mx30 READER CONFIGURATION
Beeper¹
Meaning
H H H H Correct entry or exit from Configuration mode
L Good read of a command
L L L Command read error
164
