User manual

GRYPHON™ Dx30/Mx30
6
6.2 GRYPHON™ MX30
Electrical Features
Battery Type 2 AA NiMh* batteries1.2 V
Time of recharge NiMh max 5 hours with NiMh 2100 mAh batteries
Operating autonomy
(typ. continuous reading)
typical 40000 reads with NiMh 2100 mAh
batteries
Indicators LED, Good Read Spot, Beeper
Max scan rate 270 scans/sec
Optical Features
Sensor CCD solid state (3648 pixels)
Illuminator LED array
Wavelength 630 ~ 670 nm
Max. LED Output Power 0.33 mW
LED safety class Class 1 EN 60825-1
Reading field see reading diagram
Max. Resolution
Gryphon Mx30-Std Gryphon M130-LR
0.076 mm (3 mils) 0.11 mm (4.3 mils)
PCS minimum 15% (Datalogic Test Chart)
Radio Features
Working frequency 433.92 MHz
Bit rate 19200 baud
Range (in open air) 30 m.
System Configuration OM-GRYPHON™ STARGATE™
Max. number of devices per base
stations
16 255
Max. number of devices in the same
reading area
2000
Environmental Features
Working Temperature
0° to + 40 °C / 32° to 104 °F
Storage Temperature
(without battery)
-20° to + 70 °C / - 4° to 158 °F
Humidity 90% non condensing
Drop resistance IEC 68-2-32 Test ED
1.8 m (5 ft. 11 in.)
Protection class IP30
Mechanical Features
Weight (without batteries) about 245 g. / 8.64 oz
Dimensions 179 x 81 x 98 mm / 7.04 x 3.18 x 3.85 in
Material ABS and Polycarbonate molded with rubber
* It is possible to employ also NiCd or non-chargeable Alkaline AA batteries.
