Table Of Contents

CONTENTS
GENERAL VIEW
INTRODUCTION
INSTALLATION
- GRYPHON™ DX30 INTERFACE CABLE CONNECTIONS
- OM-GRYPHON™ INTERFACE CABLE CONNECTIONS
- RS232 CONNECTION
- USB
- IBM USB POS
- WEDGE CONNECTION
- PEN EMULATION CONNECTION
- GRYPHON™ MX30 BATTERY MAINTENANCE
GRYPHON™ MX30 SYSTEM AND NETWORK LAYOUTS
- STAND ALONE LAYOUTS
- MULTIDROP STAR-SYSTEM™ NETWORK LAYOUTS
  - Host Master Layout
CONFIGURATION
- CONFIGURATION METHODS
- SETUP PROCEDURES
- GRYPHON™ DX30 SETUP
- GRYPHON™ MX30/OM-GRYPHON™ STAND ALONE SETUP
  - Using Multiple M-Series Readers With Same Cradle
  - Gryphon™ M/STAR-Modem™ in Stand Alone Mode
- GRYPHON™ M/STAR-SYSTEM™ SETUP
- INTERFACE SELECTION
- USB READER CONFIGURATION
- CHANGING DEFAULT SETTINGS
RS232 PARAMETERS
- Baud Rate
- Parity
- Data Bits
- Stop Bits
- Handshaking
- Ack/Nack Protocol
- Fifo
- Inter-character Delay
- Rx Timeout
- Serial Trigger Lock
USB PARAMETERS
- Handshaking
- Ack/Nack Protocol
- Fifo
- Inter-character Delay
- Rx Timeout
- Serial Trigger Lock
- Keyboard Nationality
- Fifo
- Inter-character Delay
- Inter-code Delay
- Control Character Emulation
- USB Keyboard Speed
WEDGE PARAMETERS
- Keyboard Nationality
- Caps Lock
- Caps Lock Auto-Recognition (IBM AT compatible only)
- Num Lock
- Inter-character Delay
- Inter-code Delay
- Keyboard Setting
- Control Character Emulation
PEN EMULATION
- Operating Mode
- Minimum Output Pulse
- Conversion to Code 39 and Code 128
- Overflow
- Output Level
- Idle Level
- Inter-Block Delay
DATA FORMAT
- Code Identifier
- Custom Code Identifier
- Header
- Terminator
- Special Keys
- Field Adjustment
- Field Adjustment Character
- Code Length Tx
- Character Replacement
- Address Stamping (Mx30 Series Only)
- Address Delimiter (Mx30 Series Only)
POWER SAVE
- Scan Rate
- Sleep State/USB Suspend
- Enter Sleep Timeout
- Standby
READING PARAMETERS
- Hand-Held Operation
- Stand Operation
- Hardware Trigger Mode
- Trigger-off Timeout
- Flash Mode
- Reads per Cycle
- Safety Time
- Beeper Intensity
- Beeper Tone
- Beeper Type
- Beeper Length
- PDF Decoding Recognition Intensity
- Good Read Spot Duration
- Automatic Operation Aiming Light
DECODING PARAMETERS
- Ink Spread
- Overflow Control
- Interdigit Control
- Decoding Safety
- Puzzle Solver™
CODE SELECTION
- EAN/UPC Family
- 2/5 Family
- Code 39 Family
- Code 128 Family
- Code 93
- Codabar Family
- MSI
- Plessey
- Telepen
- Delta IBM
- Code 11
- Code 16K
- Code 49
- PDF417
- RSS Codes
ADVANCED FORMATTING
- Concatenation
- Advanced Formatting
RADIO PARAMETERS
- Radio Protocol Timeout
- Power-Off Timeout
- Beeper Control for Radio Response
- Battery Type
- Single Store
REFERENCES
- RS232 PARAMETERS
- PEN PARAMETERS
- DATA FORMAT
- POWER SAVE
- READING PARAMETERS
- DECODING PARAMETERS
- RADIO PARAMETERS (MX30 SERIES ONLY)
- CONFIGURATION EDITING COMMANDS
- CONFIGURATION COPYING COMMANDS
- C-GRYPHON™ CONFIGURATION
- DEFAULT PARAMETERS FOR POS TERMINALS
TECHNICAL FEATURES
- GRYPHON DX30
- GRYPHON™ MX30
- OM-GRYPHON™ / C-GRYPHON™
- SYSTEM AND RADIO FEATURES
- STATUS INDICATORS
- READING DIAGRAMS
A HOST CONFIGURATION STRINGS
B CODE IDENTIFIER TABLE
C HEX AND NUMERIC TABLE

Enter Configuration Exit and Save Configuration

Ì$+;Î

CODE SELECTION

Ì$

?Î

Example:

The fol th the

34/43

1 D ON by P fix.

2. 434/43 reading and transmission with ADD ON of all EAN/UPC barcodes

st ixes.

3. 97 transmission with ADD ON f all EAN/UPC barcodes starting

with 977 prefix.

4. 978: enables reading and transmission wi ADD ON of all arting

with 978 prefix.

EAN/UPC Autodiscrimination ADD ON by

Prefix

434/439

ÌAA8Ad19Î

lowing string allows reading and transmitting with ADD ON all EAN/UPC starting wi

9, 977 and 978 prefixes: 4

. EAN/UPC Autodiscrimination AD re

9: enables

arting with 434/439 pref

7: enables reading and o

th EAN/UPC barcodes st

ÌET3434ET4439ÉÎ

ÌET7977QÎ

977 8

ÌET8978ZÎ

To clear the current prefix selections:

1. Cancel all Selections

Cancel All Selections

ÌET0wÎ
