User Manual

GRYPHON™ BT
13
UK/US
C-GRYPHON
Electrical Features
Supply voltage 9..28 Vdc
Power consumption max. 8 W (charging) *
Indicators
Battery charging (red)
Charge completed (green)
Power (yellow)
Time of recharge NiMh / NiCd batteries: 4 hours
Environmental Features
Working temperature 0° to +40 °C / 32° to 104 °F
Storage temperature -20° to +70 °C / - 4° to 158 °F
Humidity 90 % non condensing
Protection class IP30
Communications
Interface RS232
Baud Rate 9600
Data Bits 8
Stop Bit 1
Parity None
Mechanical Features
Weight about 250 g. / 8.81 oz
Dimensions 208 x 107 x 55.5 mm / 8.1 x 4.2 x 2.18 in
Material ABS
* Having a switching regulator inside, the C-GRYPHON draws the same
power, regardless of the supply voltage, i.e. as the input voltage increases
the current drawn decreases.
