B-9
User’s Guide for Express™ and Select™ Printers
Print ribbon cartridge
The print ribbon cartridge is part number 555545-999.
Be sure to change the print ribbon setting in the printer driver when you change
the type of print ribbon.
Figure B-10: Print ribbon cartridge
Card cartridge
The card cartridge is different from Express and Select printers.
•
Express printers have green cartridges, which are part number 555540-998.
•
Select printers have gray cartridges which are part number 555540-997
Figure B-11: Card cartridge
i
