C-9
User’s Guide for Express™ and Select™ Class Printers
Figure C-5: Settings dialog box
7 Select the Port Settings tab.
8 Select the following settings:
9 When the settings are correct, click OK to save settings and close the dialog box.
♦
Setting Value
Bits per second 9600
Data bits 8
Parity None
Stop bits 1
Flow control None
