Technical data
` Printer specifications
For more information on printer specifications as well as interface specifications,
refer to the User guide on the Online CD-ROM.
Printing method 24-pin Dot matrix impact printer
Character pitch 10, 12, 15, 16.6, 17.1, 20, 24 characters/inch and
proportional type (emulation-dependent)
Line spacing Optional in microsteps
n/60 inches n = 0 to 127
n/180 inches n = 0 to 255
n/360 inches n = 0 to 255
Print width 194 characters/line at 10 cpi
112 characters/line at 12 cpi
141 characters/line at 15 cpi
Print speed LQ: 133 cps; DQ: 400 cps
Interface serial (RS232C), parallel (compatible Mode, ECP),
USB 2.0 (Full speed)
Nominal voltage 120V ± 10% (USA) or 230V ± 10% (Europe)
Line frequency 50/60Hz ± 3%
Network form For use in power distribution systems with neutral and
protective earth conductors (TN)
Rated current intake Operation (maximum): US: 1.30 A; EU: 0.59 A
Standby US: 0.11 A; EU: 0.072 A
Apparent power
consumption
Operation (maximum): US: 89.7 VA; EU: 93.6 VA
Standby US: 88.8 VA; EU: 11.4 VA
Sound output level L
WAd
7.1 dB in operation
Sound pressure level
LpAm
55 dB in operation
Dimensions Height: 168 mm, Width: 378 mm, Depth: 280 mm
Weight Standard = 9,10 kg, MSR-H = 9,95 kg
Approvals
DIN EN 60 950 / VDE 0805, TUV (EN 60950) / Certified
CE Mark, UL 60950 3rd Edition / C-UL (CSA C22.2 No
60950-00) new reversion, IEC 60950-1, EN 55022 :1998
(Class B), EN 55024 :1998, FCC PT 15B : 2000
(Class B), EN61000-3-2 :2000, EN61000-3-3 :1995,
Energy Star
