SD303056/12-09.01

Danze, Inc., 2500 Internationale Parkway, Woodridge, IL 60517, USA danze.com

Contractor: Contact #:

Job Name: Location:

Submittal Information:

D303056 D303056

SPECIFICATIONS

Warranty

Danze products are covered by a manufacturer’s

limited "lifetime" warranty for manufacturing defects.

Description

• Ceramic disc valve

• 5" high spout, 4" spout length

• Metal pop-up drain assembly

• 3 hole mount

BANNOCKBURN™ TWO HANDLE MINI-WIDESPREAD LAVATORY FAUCET

Finishes Available

Model

D303056 (Replaces D307356 series)

Standards

• UPC/cUPC

• NSF 61-9

• Energy policy act of 1992

• CSA B125

• ADA Accessibility Guidelines for

Buildings and Facilities -

4.27.4 Controls and Mechanisms

• ASME A112.18.1

• Meets CA AB-1953

MEETS

CA AB-1953

Less than 0.25% lead content

Flow Rate

0.5

1.5

20 40 60 80

PSI

GPM

• Chrome

• Other: Refer to Price List for

additional finish

5 1/8"

(130mm)

4 1/8"

(104mm)

2 5/8"

(67mm)

10°

Ø2 1/8"

(Ø54mm)

1 1/2"-18UNEF

(Ø1 1/2")Max

(Ø38mm)

(203mm)

Ø1 1/4"

(Ø32mm)

8"Max

(203mm)

1/2"(min)

13mm(min)

3 7/16"

(87mm)

1 1/8"~1 13/16"

(28mm~46mm)

9 3/16"~13 1/8"

(233~334mm)

4"~8"

(102~203mm)

Ø2"

(Ø51mm)

Ø1 7/8"

(Ø48mm)

3 1/16"

(77mm)

1/16"~2"

(1~51mm)

8 1/4"

(210mm)

1"-20UNEF

5/8"-18UNF

1/2"-14NPSM
