Datasheet
Data sheet
DH-SMT/PL
VD.SH.A2.02 © Danfoss 11/2007 3
SONOMETER
TM
2000 – Ultrasonic heat meter
Ordering
AAA BB - C D E F G H - I J K L M - NN O
- - -
AAA - application
accessories only 000
only temperature sensors 4TS
heat meter for heating 2HE
heat meter for cooling (only with SONO 2500CT) 2CO
heat meter for heating/cooling (only with SONO 2500 CT) 2HC
only flow sensor for heating 15H
for heat meter for cooling (heating/cooling) up to qp 6m³/h use SONOMETER™1000
O - verification
0 without approval mark and test protocol
1 with approval mark and test protocol
2
with approval mark and verification /
declaration of conformity
F - power supply
not relevant / with external power supply
1
0
battery 3.0V DC (C-cell)
2
1
battery 3.6V DC (D-cell)
3
2
mains unit 230V AC
3
3
mains unit 24V AC
3
4
1
only for flow sensor
2
only for flow sensor SONO 1500 CT
3
only for complete heat meter (power supply for calculator); only external
supply (from calculator) for flow sensor; SONO 1500 CT in combination with
calculator possible
GH - interface modules
modules slot 1
not relevant / no module in slot 1 0
M-Bus module A
RS-232 module B
Real Data radio module C
pulse input module (2 inputs) D
modules slot 2
not relevant / no module in slot 2 0
pulse output module (2 outputs) K
pulse input module (2 inputs) L
combined module (2 inputs / 1 output) M
(standard setting for pulse input modules: 100 l/pulse standard setting for pulse
output modules: energy and volume, pulse value is the last digit in the display)
I - energy units
0 not relevant / only flow sensor
A kWh (without digit after comma) only for 0.6 - 6 m³/h
B MWh (with 1 digit after comma)
C MWh (with 2 digits after comma)
D MWh (with 3 digits after comma) only for 0.6 - 6 m³/h
E GJ (with 1 digit after comma)
F GJ (with 2 digits after comma)
G GJ (with 3 digits after comma) only for 0.6 - 6 m³/h
H Gcal (with 1 digit after comma)
I Gcal (with 2 digits after comma)
J Gcal (with 3 digits after comma) only for 0.6 - 6 m³/h
K MBtu (with 1 digit after comma)
L MBtu (with 2 digits after comma)
M MBtu (with 3 digits after comma) only for 0.6 - 6 m³/h
(units with other digits after comma on request)
J - temperature sensors (pair)
0 not relevant / without sensors
A Pt 500 / direct sensor ø 3.3 mm / 1.5 m cable
B Pt 500 / direct sensor ø 3.3 mm / 3.0 m cable
C Pt 100 / ø 5.2 mm / 2 m cable
E Pt 500 / ø 5.2 mm / 2 m cable
F Pt 500 / ø 5.2 mm / 3 m cable
G Pt 500 / ø 5.2 mm / 5 m cable
H Pt 500 / ø 5.2 mm / 10 m cable
I Pt 500 / ø 6.0mm / 1,5m cable
J Pt 500 / ø 6.0 mm / 3 m cable
K Pt 500 / ø 6.0 mm / 5 m cable
L Pt 500 / ø 6.0 mm / 10 m cable
M Pt 500 / ø 6.0mm / 20m cable (heat meter without approval)
(standard: with EN-approval)
L - accessories / pocket
0 without
for 5.2 mm temperature sensors (pair)
A brass-pockets, 34 mm
B brass-pockets, 50 mm
C brass-pockets, 70 mm
D brass-pockets, 85 mm
E brass-pockets, 120 mm
for 6 mm temperature sensors
K brass-pockets, 40 mm
L brass-pockets, 85 mm
M brass-pockets, 120 mm
N stainless steel-pockets, 85 mm
O stainless steel-pockets, 120 mm
P stainless steel-pockets, 155 mm
Q stainless steel-pockets, 210 mm
R ball valve DN 15 - ½” for direct sensor (1 piece)
S ball valve DN 20 - ¾” for direct sensor (1 piece)
T ball valve DN 25 - 1” for direct sensor (1 piece)
U adapter for direct sensor (1 piece)
M - connections (sets)
0 not relevant / without
1 screwing set R ½” x G ¾ B
2 screwing set R ¾” x G 1 B
3 screwing set R 1” x G 1¼ B
4 screwing set R 1½ x G 2 B
5 weld-on tail pieces x G 1¼ B
6 weld-on tail pieces x G 2 B
K - temperature sensor mounting
0 not relevant / only flow sensor
1
one sensor mounted in the SONO 1500CT (only for direct sensor and
5.2 mm sensor qp 0.6 to 2.5 m³/h)
2 indirect mounting (2 free sensors)
BB - (for) flow sensor (type SONO 1500 CT)
not relevant / no flow sensor 00
qp 0.6 m³/h / 110mm thread / DN 15 / G¾B / 1 litre/pulse 1A
qp 0.6 m³/h / 130mm thread / DN 20 / G1B / 1 litre/pulse 1B
qp 0.6 m³/h / 190mm thread / DN 20 / G1B / 1 litre/pulse 1C
qp 1.0 m³/h / 110mm thread / DN 15 / G¾B / 1 litre/pulse 1D
qp 1.0 m³/h / 130mm thread / DN 20 / G1B / 1 litre/pulse 1E
qp 1.0 m³/h / 190mm thread / DN 20 / G1B / 1 litre/pulse 1F
qp 1.5 m³/h / 110mm thread / DN 15 / G¾B / 1 litre/pulse 1G
qp 1.5 m³/h / 130mm thread / DN 20 / G1B / 1 litre/pulse 1H
qp 1.5 m³/h / 190mm thread / DN 20 / G1B / 1 litre/pulse 1I
qp 2.5 m³/h / 130mm thread / DN 20 / G1B / 1 litre/pulse 1J
qp 2.5 m³/h / 190mm thread / DN 20 / G1B / 1 litre/pulse 1K
qp 3.5 m³/h / 260mm thread / DN 25 / G1¼B / 10 litre/pulse
1L
qp 6 m³/h / 260mm thread / DN 25 / G1¼B / 10 litre/pulse
1M
qp 0.6 m³/h / 190mm flange DN 20 / 1 litre/pulse 2A
qp 1.0 m³/h / 190mm flange DN 20 / 1 litre/pulse 2B
qp 1.5 m³/h / 190mm flange DN 20 / 1 litre/pulse 2C
qp 2.5 m³/h / 190mm flange DN 20 / 1 litre/pulse 2D
qp 3.5 m³/h / 260mm flange DN 25 / 10 litre/pulse 2E
qp 3.5 m³/h / 260mm flange DN 32 / 10 litre/pulse 2F
qp 6 m³/h / 260mm flange DN 25 / 10 litre/pulse 2G
qp 6 m³/h / 260mm flange DN 32 / 10 litre/pulse 2H
(standard: without galvanic isolation; galvanic isolation on request)
BB - (for) flow sensor (type SONO 2500 CT)
qp 10 m³/h / 300mm thread / DN 40 / G2B / 10 litre/pulse 1N
qp 10 m³/h / 300mm flange DN 40 / 10 litre/pulse 2W
qp 15 m³/h / 270mm flange DN 50 / 10 litre/pulse 2X
qp 25 m³/h / 300mm flange DN 65 / 100 litre/pulse 2Y
qp 40 m³/h / 300mm flange DN 80 / 100 litre/pulse 2Z
C - nominal pressure
not relevant 0
PN16 C
PN25 D
D - cable length between calculator and flow sensor
not relevant 0
2.5m (standard) A
5m B
10m C
E - installation
not relevant 0
forward F
return R
NN - country code
00 Neutral code with doc’s in English
BY Belarus
BA Bosnia
BG Bulgaria
CN China
HR Croatia
CZ Czech Republic
DK Denmark
EE Estonia
KZ Kazakhstan
KG Kirghizia
LV Latvia
LT Lithuania
MK Macedonia
MD Moldova
XM Montenegro
PL Poland
RO Romania
RU Russia
CS Serbia
SK Slovak Republic
SI Slovenia
TJ Tajikistan
TM Turkmenistan
UA Ukraine
UZ Uzbekistan
