Datasheet

SONOMETER
TM
2000 – Ultrasonic heat meterData sheet
DH-SMT/PL
VD.SH.A2.02 © Danfoss 11/200716
Dimensions
SONO 1500 CT
Nominal size q
p
=0.6 m³/h q
p
=1.0 / 1.5 m³/h q
p
=2.5 m³/h
q
p
=3.5 m³/h q
p
=6.0 m³/h
L [mm] 110 130 190 190 110 130 190 190 130 190 190 260 260 260 260 260 260
L1 [mm] 190 230 190 230 230 - - - - - -
L2 [mm] 90
B [mm] 65.5
H [mm] 54.5 56.5 56.5 56.5 54.5 56.5 56.5 56.5 56.5 56.5 56.5 61 61 61 61 61 61
h [mm] 14.5 18 18 47.5 14.5 18 18 47.5 18 18 47.5 23 50 62.5 23 50 62.5
AGZ
G¾B
DN15
G1B
DN20
G1B
DN20
FL
DN20
G¾B
DN15
G1B
DN20
G1B
DN20
FL
DN20
G1B
DN20
G1B
DN20
FL
DN20
G1¼B
DN25
FL
DN25
FL
DN32
G1¼B
DN25
FL
DN25
FL
DN 32
AGV R½ R¾ R¾ - R½ R¾ R¾ - R¾ R¾ - R1 - - R1 - -
D [mm] - - - 105 - - - 105 - - 105 - 114 139 - 114 139
d [mm] - - - 14 - - - 14 - - 14 - 14 18 - 14 18
F [mm] - - - 95 - - - 95 - - 95 - 100 125 - 100 125
K [mm] - - - 75 - - - 75 - - 75 - 85 100 - 85 100
Weight [kg] 0.6 0.61 0.63 2.7 0.6 0.61 0.63 2.7 0.61 0.63 2.7 1.35 3.35 4.65 1.35 3.35 4.65
FL - flanged connection
