Operating instructions

More than one secondary heat pump
3 4 5 6
1
2
8
7
1 Router/Switch
2 Possibility of internet access via router
3 Primary (controlling) heat pump with IP address e.g.
192.168.000.100
4 Secondary heat pump with IP address e.g. 192.168.000.102
5 Secondary heat pump with IP address e.g. 192.168.000.103
6 Secondary heat pump with IP address e.g. 192.168.000.104
X Secondary heat pump with IP address e.g. 192.168.000.XXX
7 Online Web server and database
8 Online web browser
The secondary heat pump must always point to the primary heat
pump IP address.
Menu settings
N
If more than one heat pump is installed, network settings must be en-
tered in every one of the units.
N
Contact your network administrator if settings in a router or other net-
work equipment is required.
1. Press in the upper left corner of the Start screen.
2.
Press .
3. Press the text System settings
4. Press the text Network settings
For automatic IP-settings:
1.
Set Dhcp/static to 0 (factory default)
2.
Press to return to System settings.
Or press in the upper left corner to return to the Menu screen.
For manual IP-settings:
1.
Set Dhcp/static to 1
2. Press on each relevant figure in the IP-address and then on respectively + and – to change the setting.
3. Repeat previous step for Network mask, IP gateway etc.
4.
Press to confirm the setting.
5.
Press to return to System settings.
Or press in the upper left corner to return to the Menu screen.
Commissioning
DHP-M
