Operating instructions

Comfort adjustment, to change temperature
Comfort adjustment means moving the whole curve upwards or downwards.
Drag clockwise or anticlockwise to raise or lower the offset. Each point represents an increase/
decrease of approximately 1°C of the supply line temperature, depending on comfort factor set-
tings.
Alternatively, press
or
NOTE: This option should be primarily used for temporary temperature adjustments. When permanently changing the indoor tempera-
ture for a more precise indoor climate, change the heat curve settings.
5.5
Adjusting the Heat Curve
The Curve indicator has two modes that can be toggled by pressing the Curve indicator symbol.
40
When lit, the curve is adjusted as one unit.
40
When not lit, individual curve points can be moved separately.
1. Press on the Start screen to open the Menu screen.
2.
Press
3.
Press if the Heat curve is not shown.
4. There are two ways of adjusting the heat curve:
▪
If the Curve indicator
40
is lit, press or to adjust the entire curve.
Or:
▪
If the Curve indicator
40
is not lit individual points can be moved separately by pressing
and to the desired temperature.
5.
Confirm the new selection by pressing
