Data Sheet

Data Sheet Danfoss Ally™ Radiator Thermostat
2 | © Danfoss | FEC | 2020.09
AI319043912283en-000103
Specifications
Thermostat type Programmable electronic radiator valve controller
Recommended use Residential (pollution degree 2)
Actuator Electromechanical
Display LCD with white backlight
Software classification A
Control PID
Power supply 2 x 1.5 V alkaline AA batteries
Power consumption 3 mW in standby, 1.2 W when active
Trasmission Frequency / Power 2,4 GHz / < 40 mW
Battery life Up to 2 years
Low battery signal Battery icon will flash in display.
Ambient temperature range 0 to 40 °C
Transportation temperature range -20 to 65 °C
Maximum water temperature 90 °C
Temperature setting range 5 to 35 °C
Clock accuracy +/- 10 min/year
Spindle movement Linear, up to 4.5 mm, max. 2 mm on valve (1 mm/s)
Noise level <30 dBA
Safety classification Type 1
Open-window function Activated at temperature decrease or by ZigBee command
Weight (incl. batteries) 198 g (with RA adapter)
IP class
20 (not to be used in hazardous installations or in places
where it will be exposed to water)
Integrations* Partner API, Google Assistant, Amazon Alexa
Approvals, markings etc.
* Requires Danfoss Ally™ Gateway
